Educational Material Extrusion Laminating Machine With Winding System
1. Double-sided adhesive release papers
Double-sided adhesive release papers and photo papers, etc
2. Double-sided adhesive release papers
Technical parameters
| Machine specification |
1200mm/1400mm/1700mm |
| Effective width |
Max1100mm/1300mm/1600mm |
| Machine speed |
350m/min |
| Extruder |
LD-90mm/LD-100mm “Automatic lifting type extruder” |
| Extruder power |
45-55kw |
| Extruder output |
Max 200kg/h or 250kg/h |
| Used resins |
Coated resins like LDPE/LLDPE/PP/EVA/EAA |
| Coating thickness |
8-45μm |
| Thickness uniformity |
≤±5％ |
| Unwinding diameter |
Max Φ1200mm |
| Rewinding diameter |
Max Φ1200mm |
| Basic material |
Paper(35-200g/㎡) |
| Tension control |
Full automatic tension roller closed-loop constant tension control of unwinder and rewinder |
| Control mode |
Human-machine interface, extrusion thickness is automatically precision calculated by computer, whole machine linkage control |
| Frequency converter |
Imported AC digital vector control inverter |
| Machine Dimension(L*W*H) |
19.2/13.2×(9.5-12)×4.5m |
3. Double-sided adhesive release papers
Main Features
1) Double Shaft-less paper roll stands suitable for 3-6 inch paper core,automatic lift ,easier operation .
2) Auto splicer device realize paper in 150-300 m/min speed exchange without decrease machine line speed
3) Ultrasonic type EPC system,makes frequent replacement materials operation more simple
4) Hydraulic lamination structure design , can make coating thinner and firm .
5) Trimming device make the finished coated paper rolls even
6)Special cutting knife and rewinder design makes high speed rewinding shafts exchange possible
Why Choose This Paper Laminating Machine?
For manufacturers looking to improve paper coating efficiency and finished-product consistency, the rapid cooling system is an important part of the production process. By accelerating heat removal from the freshly extruded polymer layer, it helps stabilize the coating before winding and supports continuous operation.
The available 1200mm, 1400mm, and 1700mm working widths provide flexibility for different production scales. Combined with extrusion coating technology and adjustable process parameters, the machine offers a practical solution for manufacturers producing coated paper for packaging and industrial converting.
As a professional extrusion coating and lamination equipment manufacturer, Laiyi Packing Machinery provides equipment solutions tailored to substrate specifications, coating materials, production capacity, and finished-product requirements.
Contact us to discuss your paper width, coating material, target coating thickness, and production speed so we can recommend a suitable machine configuration.
