Adhesive Bopp Packing Coating Lamination Machine

Adhesive Bopp Packing Coating Lamination Machine

MOQ: 1 set
Price: $70,000-200,000
Standard Packaging: Sea worthy packaging
Delivery Period: 90-150 days
Payment Method: L/C , T/T
Supply Capacity: Max 20sets per month
Detail Information
Place of Origin
China
Brand Name
Laiyi
Model Number
ADPC
Type:
Extrusion Lamiatng Machine
Condition:
New
Automatic Gra:
Automatic
Driven Type:
Mechanical
Voltage:
380V
Lifetime:
More Than 10 Year
Minimum Order Quantity:
1 set
Price:
$70,000-200,000
Packaging Details:
Sea worthy packaging
Delivery Time:
90-150 days
Payment Terms:
L/C , T/T
Supply Ability:
Max 20sets per month
High Light:

extrusion coating lamination machine

,

ldpe coating machine

Product Description

Adhesive Bopp Packing Coating Lamination Machine Max 1100/1300/1600mm





1. Cup Paper Extrusion Laminating Machine

Technical parameters

Machine width 1200/1400/1700mm
Effective width Max 1100/1300/1600mm
Machine speed 300m/min
Screw diameter LD-100mm/LD-115mm
Extruder output Max 400kg/h or 550kg/h
Used resins Coated resins like LDPE/PP/PBS/PLA
Coating thickness 8-45μm
Maxdiameter Unwinder:Φ1500mm;Rewinder:Φ1800mm
Basic material Paper(100-400gsm)
Dimension(L*W*H)
Double:30.7*(9.5-11)*3.8m

Single:21.5*(9.5-11)*3.8m



2. Cup Paper Extrusion Laminating Machine

Product Application

Jiangsu Laiyi designs and manufactures extrusion laminating/coating lines on the strength of a thorough expertise in the co-extrusion of special polymers - customized and modular layout to meet the demand for special products; - chill-roll unit with precise temperature control - rapid cooling system - special winders and unwinders suitable for any final application.

Jiangsu Laiyi extrusion and co-extrusion units at the forefront of technology, boasting a high manufacturing quality with components suitable for processing also corrosive polymers. we has focused on high performance extruders with special screw design for a wide range of materials like LDPE, SURLYN, EVA, EAA, PP, with customized solutions including different layers, sizes and die widths.

3.Main Features

1) Double Shaft-less paper roll stands suitable for 3-6 inch paper core,automatic lift ,easier operation .

2) Auto splicer device realize paper in 150-300 m/min speed exchange without decrease machine line speed

3) Ultrasonic type EPC system,makes frequent replacement materials operation more simple

4) Hydraulic lamination structure design , can make coating thinner and firm .

5) Trimming device make the finished coated paper rolls even

6)Special cutting knife and rewinder design makes high speed rewinding shafts exchange possible
